A cross-platform HDR ⇄ SDR conversion SDK
Real-time, parametric and fully invertible.
Easily add high-quality, real-time and fully parametric HDR ⇄ SDR conversions to your solution. The ORION-CONVERT™ SDK integrates into cloud-based services, Linux or Windows-based hardware products, and desktop software — including macOS.
Mathematically defined. Mathematically invertible.
ORION-CONVERT™ takes a novel three-step approach to HDR ⇄ SDR conversion, with a simple, intuitive set of user controls. The intent isn't to adjust these continuously during a broadcast — rather, settings suitable for a situation are found once and used as presets.
Because the transform is mathematically defined, it's mathematically invertible: apply a down-conversion, then run the identical parameters in reverse, and the compressed highlights expand back to HDR for a pixel-perfect round trip.
ORION-CONVERT™ brings real-time, floating-point precision to colour conversion — the same technology behind the Emmy-nominated, IBC 2021 Special Award-winning NBCU LUT-based workflow used at the Tokyo Olympics and many of the biggest international sporting events since 2020.
Workflow specs
- EOTFs
- SDR, HLG, PQ, S-Log3, LogC3
- Gamuts
- BT.709, BT.2020, LogC3, S-Gamut3, S-Gamut3.Cine
- Modes
- Scene-light and Display-light
- Compliance
- ITU BT.2100 and BT.2408
- Presets
- NBCU, British TV, plus HLG/S-Log3 Live & Mild looks
Everything the engine gives you
- Invertible conversionsSDR, HLG, PQ and S-Log3 with a perfect roundtrip.
- Dual highlight compressionCompression/expansion and gamma compensation built into the core transform.
- NBCU and “BBC emulation” presetsFloating-point presets used at major broadcast events.
- Full-range, narrow-range, float and integerFormat support across the whole pipeline.
- Parametric looksFully invertible emulation presets for Sony's Live and Mild Looks (HLG and S-Log3).
- Blocking and non-blocking APIsConfigurable to fit your threading model.
- Whole-frame and subframe processingProcess exactly the region you need.
- Multi-threaded processingInternally- or externally-managed.
- Optional internal frame bufferMemory management handled for you, or bring your own.
- CUDA and Metal GPU accelerationHardware-accelerated on every supported platform.
- Windows, Linux and macOS binariesOne SDK, every major platform.
- Flexible licensing optionsTalk to us about what fits your product.
What's in the box
- C++ headers
- Libraries for Windows, Linux and macOS
- API reference documentation
- Full Qt GUI sample source code, with Blackmagic DeckLink HDR monitoring
- Performance tester and source code for measuring frame rate and latency on target hardware
- Command-line frame (TIFF) converter sample code
Supported targets
| Platform | Arch | GPU |
|---|---|---|
| Windows 10+ | x64 | CUDA |
| Linux | x64 | CUDA |
| macOS 10.15+ | x64, arm64 | Metal |
Compilers: MS Visual Studio / MinGW / GCC (Windows), GCC / Clang (Linux), Clang (macOS).
AJA Video Systems ColorBox
ORION-CONVERT™ brings parametric control and floating-point precision to AJA's real-time ColorBox hardware solution.
Visit AJA ColorBox
